Weld Knight™ NANOCHEM® Replacement Canister

USD $3,266.00

Weld Knight™ NANOCHEM® Replacement Canister

USD $3,266.00
Part Number:    UEQ Weld Knight Canister
   Availability:   Ships within 3-5 days from Longmont, CO.


Request Quote

Product Description

MATHESON made in the USA





NANOCHEM® Weld Knight™ purifiers provide purge and shield gas purification for welding applications. Weld gas impurities, such as moisture and oxygen, adversely affect weld quality. These impurities are present in gas cylinders and can also be introduced through leaks in the line or during cylinder changes.

NANOCHEM® OMX™ and INX-Plus™ media react chemically and irreversibly with these impurities to deliver consistently pure gas to the weld site, improving weld quality. NANOCHEM® MigMix media is specifically designed to purify Ar/O2, Ar/CO2 and other O2, or CO2 blends.

NANOCHEM® MigMix provides customers with the ability to use blended gas without the worry of reducing their tolerances or dilution ratios. MigMix is also better than any  media for the removal of moisture impurities.

NANOCHEM® Weld Knight™ purifiers are an economical solution for GMAW (TIG) welding and other critical welding applications.
• Flow Rates up to 530 cfh (250 slpm)
• Easy to use canister bypass mode for canister changes and extended shutdowns
• Canister can be refilled, enabling savings over purchase of spare canisters

Features and Benefits

• Removes impurities to < 10 ppb (Dew Point = -150ºF)
• Enhances weld quality, strength and appearance
• Reduces weld porosity and oxidation
• Increases weld electrode lifetime – No need to stop welding to grind/replace electrode
• Reduces weld rejects
• Filters at canister inlet and outlet
• Operates at room temperature
• No power requirements
• NANOCHEM® Inorganic Media – Prevents contamination from system upsets, such as air intrusion or connection of wrong gas cylinder
• NANOCHEM® MigMix Purifier – Designed for customers with gas blend welding needs
• Field Replaceable Canister
• New Stainless Canisters can be refilled – Savings over cost of replacement canister.  Reduction in generation of solid waste

Ordering Information
Gas Service: Argon, Helium, Nitrogen, Hydrogen, or Blends of These Gases (4N purity or Better)
Part Number For Weld Knight
Model Number
Max
Flow#
Media Standard Impurities
Removed
Extra Impurities
Removed
UEQ 10600532001 WK-500-PA-OMX 50 slpm OMX™ <100 ppt H2O, O2, CO2 LDL
UEQ 10600532018 WK-500-PA-INX-Plus 50 slpm INX-Plus™ <100 ppt H2O, O2, CO2 LDL <0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4
UEQ 10600546001 WK-700-PA-OMX 70 slpm OMX™ <100 ppt H2O, O2, CO2 LDL
UEQ 10600546018 WK-700-PA-INX-Plus 70 slpm INX-Plus™ <100 ppt H2O, O2, CO2 LDL <0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4
UEQ 10600533001 WK-2500-PA-OMX 250 slpm OMX™ <100 ppt H2O, O2, CO2 LDL
UEQ 10600533019 WK-2500-PA-INX-Plus 250 slpm INX-Plus™ <100 ppt H2O, O2, CO2 LDL <0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4

#Note: Flow rates for argon

Ordering Information
Gas Service: CO2/Argon Mix, O2/Argon Mix, CO2/Inerts Mix, or O2/Inerts Mix
Part Number For Weld Knight
Model Number
Max
Flow#
Media Standard Impurities
Removed
UEQ 10600532016 WK-500-PA-MM 50 slpm Mig Mix <45 ppb H2O
<0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4
UEQ 10600546016 WK-700-PA-MM 70 slpm Mig Mix <45 ppb H2O
<0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4
UEQ 10600533016 WK-2500-PA-MM 250 slpm Mig Mix <45 ppb H2O
<0.2 ppb Hydrocarbons except CH4
<100 ppt Halocarbons except CF4

#Note: Flow rates for argon

Materials of Construction

• Cannister: 316L stainless steel
• Media: INX-Plus™, OMX™, MigMix

Specifications

• Maximum Operating Pressure: 200 psi
• Maximum Operating temperature: 170°F (65°C)
• Cannister Inlet/Outlet:  1/4" Face Seal - Male
• Lifetime (approximate*) for (WK-500-PA): 105 cylinders
• Lifetime (approximate*) for (WK-700-PA): 147 cylinders
• Lifetime (approximate*) for (WK-2500-PA): 525 cylinders
*Based upon argon of 99.998% purity ("Pre-purified" grade) containing 3 ppm O2 and 10 ppm H2O










Safety Data Sheets (SDS)

SDS, NANOCHEM®  OMX™
